2025 Drag Specialties FatBook

M8 • PAN AMERICA • TWIN CAM • 86 & UP SPORTSTER 2025

2025 Drag Specialties FatBook cover bike is a beautiful blend of two eras of performance – it taps into the current popular “bagger racing” trend but has design cues and custom touches that are drawn from a type of custom motorcycle design that was popular a few decades earlier. “The performance bagger style is really hot right now,” Cheeseman said. “But I am really a fan of the 90s Pro Street look and style – a little more sheet metal, the overall look of the bike dropped a little lower. I wanted that Pro Street look, but to improve on the performance aspect of it with parts we didn’t have back then but are available now.” The build started with a stock 2023 Low Rider ST. Then Cheeseman and his crew took a look through the FatBook for parts that would result in a cool blend of those two styles. “There are so many good parts to choose from,” he said. “What it really came down to when making the choices was, does it really work for this build or not?” The first change was a Paul Yaffe “The Fix” rear fender kit. “That Yaffe fender is phenomenal,” ON THE COVER Cheeseman said. “It just works so well at cleaning up the rear end of the bike. And the little details like the license plate frame already being Frenched into the fender, the no taillight look,” he said. To further clean up the rear lines of the bike, Cheeseman fabricated a new set of saddlebag mounts. “It drops the bags maybe an inch or so,” he said. “It brings the line down a little bit, tucks them in more, makes it look smoother and sleeker. And the mounts are fully adjustable.” The front end uses a modified Klock Werks front fender. Cheeseman also fabricated custom fender brackets to get the ideal fit and flow of the fender line to match the Pro Street shape he wanted. The front suspension was upgraded using a Legend Suspensions 43 mm AXEO kit, and the rear suspension is now handled by a Legend Suspensions Air-A Mono kit. Braking power was upgraded with SlyFox 2-piece rotors at the front and rear. The front end also saw a set of Speed Merchant radial brake rotor caliper mounts paired with Performance Machine 4-piston brake calipers for an impressive boost in braking power. The engine features an S&S Superstreet 2-into-1 exhaust system with a stainless steel finish and a Kodlin USA Oval air cleaner kit with a black finish. Builder: Dan Cheeseman and the team at Custom Dynamics,Youngsville, NC Paint Desinger/Painter: Jason LeCavalie, Artistimo Customs, Waukesha, WI

dragspecialties.com | #SINCE1968 Cheeseman and his team also added in some custom fabrication work to areas of the bike. The front spoiler is another custom piece, hand-fabricated from aluminum by Cheeseman. “It is a pretty cool piece. I am proud of that,” he said. “I am also a big fan of symmetry on a motorcycle,” he said. “The stock fuel filler, I welded and filled the original location, moved the fuel bung to the center of the tank and integrated the dash for a cleaner look. We also fixed the front fairing angle by a few degrees, tipping it back a bit to flow with the lines better, using a hidden fairing bracket we fabricated.” The stock ignition coil is now inside the front fairing (with custom venting to allow for cooling airflow) and rerouting the ignition wiring as needed to further clean up the look. “We also made a custom top motor mount,” Cheeseman said. Lighting is upgraded all around. The front end now features a Shark Demon 2 headlight. LED fairing vent lights, windshield trim, saddlebag lights, turn signals and a series of red LED Boltz frenched into the rear saddlebag filler panels to make the bike shine – and light up when the rider hits the brakes! “The more visible, the better,” Cheeseman said. The paint is a mix of H-D Crimson Red candy over a base of Orion Silver Max combined with Kosmic Sparks Ocean Blue. “I am a bass boat/metalflake paint kind of guy,” Cheeseman said with a laugh. “But that kind of finish might have been a little too far out there. The combination is a play on the classic Drag Specialties/Parts Unlimited colors, but it still is pretty wild. I hope everyone who sees this bike finds it inspiring.”

14.BRAKES.......................... 1506-1609 15. TANKS & OIL FILTERS. . . . . . . . . . . . . . . . 1610-1566 16. DASHES & GAUGES.. . . . . . . . . . . . . . . . . 1656-1695 17. FRAMES & SUSPENSION. . . . . . . . . . . . . . 1696-1804 18. FENDERS & LICENSE PLATEFRAMES..................... 1805-1853 19. FOOTRESTS & FLOORBOARDS. . . . . . . . . . 1854-1921 20. WHEELS & AXLES.. . . . . . . . . . . . . . . . . . 1922-1955 21. HARDWARE, COVERS & GENERAL.. . . . . . . 1956-2009 OEM CROSS REFERENCE.. . . . . . . . . . . . . . . . 2010-2033 VINGUIDE........................... 2034-2036 DRAG SPECIALTIES QUICK REFERENCE CHART. . 2037-2039 INDEX.............................. 2040-2082 Please Note: All 86 & Up Sportsters are in this 2025 FatBook™ All Evolution Big Twins are in the 2024-25 OldBook™ 1. WINDSHIELDS & FAIRINGS.. . . . . . . . . . . . . . . . . 8-85 2. AUDIO, COMMUNICATION & MOUNTS. . . . . . . . 86-193 3. SADDLEBAGS & LUGGAGE.. . . . . . . . . . . . . . 194-304 4. SEATS & SISSY BARS. . . . . . . . . . . . . . . . . . 305-514 5.EXHAUST........................... 515-637 6. FUEL/AIR SYSTEMS.. . . . . . . . . . . . . . . . . . . 638-737 7.ENGINE............................ 738-878 8. TRANSMISSION & DRIVELINE.. . . . . . . . . . . . 879-980 9.GASKETS&SEALS................... 981-1013 10.ELECTRICAL....................... 1014-1113 11.LIGHTING......................... 1114-1262 12. HANDLEBARS, CONTROLS & MIRRORS. . . . 1263-1438 13.CABLES.......................... 1439-1505 2025

5 IMPORTANT INFORMATION: EMISSIONS REGULATIONS NOTE: The California Air Resources Board (“CARB”) does not permit the use of aftermarket emissions-related part(s) that alter the performance of OEM emissions-related devices unless CARB has issued an Executive Order, other than on racing vehicles on closed courses. Check your local laws and manufacturer’s information. More California exhaust information is available at www.arb.ca.gov/. NOTE: Parts designated as “Race Only” are for use only on vehicles used for competition racing and are not for use on vehicles registered for use on public roads. Sale and/or installation of “Race Only” parts in any way inconsistent with this warning is prohibited and may result in enforcement by the U.S. EPA under the federal Clean Air Act. “RACE ONLY” PARTS ARE NOT LEGAL FOR SALE IN CALIFORNIA ON ANY POLLUTION CONTROLLED MOTOR VEHICLES. NOTE: Aftermarket products, including but not limited to exhausts, catalytic converters, oxygen sensors, fuel/a ir controller modules, air filter kits, camshafts, O2 eliminators, and carburetors and jet kits which alter, modify, or replace emission control devices or systems of an originally compliant highway motorcycle, are not legal for sale or street use in California unless they have been issued a CARB Executive Order. Aftermarket emissions-related products which have not been issued an Executive Order or which are not aftermarket Replacement Parts, as defined in Title 13, California Code of Regulations, Section 1900(b)(2), are authorized for closed circuit race use only. Products shown may be designed, manufactured, intended and sold for closed circuit race use only and use of the same on public roads or lands may be a violation of local, state and/or federal laws. See manufacturer’s information and state and local laws to determine what is authorized for your use on your vehicle. The following emissions-related defined terms are used in this catalog (PARTS WITH THE FOLLOWING DESIGNATIONS IN THIS CATALOG ARE NOT ILLEGAL FOR SALE IN CALIFORNIA UNDER CARB REGULATIONS): • “CARB E.O.” means the specified Executive Order issued by CARB. An Executive Order constitutes an exemption by CARB from CA Vehicle Code 27156 and 38391, for sale of the part number for the make/model/year fitment(s) specified in the Executive Order. • “Replacement Part” means any aftermarket part intended to replace an original equipment emissions-related part and which is functionally identical to the original equipment part in all respects which in any way affect emissions (including durability), or a consolidated part. • “Qualified Manufacturer Declared Replacement Part” means any aftermarket part intended to replace an original equipment emissions related part and which is functionally identical to the original equipment part in all respects which in any way affect emissions (including durability), or a consolidated part, that has been evaluated and declared by the manufacturer to meet this definition and carry this categorization and designation label. This manufacturer has declared in writing that it has documentation, based upon sound engineering judgment, indicating the replacement part does not reduce the effectiveness of any required emission control device and it does not cause the modified vehicle/engine/equipment to exceed applicable emissions standards for that make/model/year fitment(s) advertised. In addition, for 49-State compliance, the following term applies: • “Qualified Manufacturer Declared 49-State Federal Emissions Compliant Part” (Not legal for sale or use in California) means any aftermarket part intended to replace an original equipment emissions-related part and that meets all EPA emission regulations by installing the element of design in all emissions-related respects to the certified configuration of the vehicle, engine, or piece of equipment. This manufacturer has declared in writing that it has fully documented the emissions testing of an appropriate test vehicle, engine, or piece of equipment that had been identically altered and that the part meets all applicable emissions standards for that make/model/year fitment(s) advertised.

6 IMPORTANT INFORMATION: EMISSIONS PRODUCT CATEGORIZATION This catalog implements use of a categorization system developed by SEMA to identify emission products’ classifications and any corresponding restrictions on sales of those products. The products will be identified as fitting one of the following categories, as determined by the vendor/manufacturer. The categorization system is set forth below. The applicable product classification is displayed under the “EMIS” column in the catalog. Category Meaning Sales Restrictions 1 This Product is covered under a CARB EO and is legal for sale and use in all 50 states. See “CARB EO” definition on page 5. No USA Territory Restrictions. 2 This product is covered under a SEMA Certified Emissions certification or has otherwise met the requirements of the EPA’s Tampering Policy and is legal for sale in states that do not mandate an EO. See “Qualified Manufacturer Declared 49-State Federal Emissions Compliant Part” definition on page 5. Blocked from sales into California 3 This product is not legal for street use on an emissions-controlled vehicle. It may be used on dedicated competition or pre-pollution-controlled vehicles only. See “Race Only” Note on page 5. *Products for which vendors did not supply classification information are by default coded as “3.” Blocked from sales in ALL states unless dealer signs acknowledgment of dealer’s obligation to ensure sales or installation of such parts are on “Competition Use” only vehicles and not for highway use. 4 This product does not require an EO in California. By nature of its design, it is legal for sale and use in all 50 states. Replacement parts included. See “Qualified Manufacturer Declared Replacement Part”definition on page 5. No USA Territory Restrictions. N/A Product not subject to emissions control regulations. No USA Territory Restrictions SEMA CATEGORIZATION LABELS

7 IMPORTANT INFORMATION: SALES OF RACE ONLY PARTS The federal Environmental Protection Agency’s policies related to tampering and defeat devices are publicly available at the following sites: https://www.epa.gov/sites/production/files/2020-12/documents/ epatamperingpolicy-enforcementpolicyonvehicleandenginetampering.pdf https://www.epa.gov/sites/production/files/2020-12/documents/ tamperinganddefeatdevices-enfalert.pdf https://www.epa.gov/sites/production/files/2021-01/ documents/caatitleiivehicleenginepenaltypolicy011821.pdf The EPA has taken civil and criminal enforcement action against companies and individuals for violations of the Clean Air Act’s tampering and defeat device prohibitions. By ordering “Race Only” parts from LeMans Corporation, d/b/a Parts Unlimited® and Drag Specialties® (“LeMans”), you, as the selling retailer, expressly acknowledge and assume all the responsibility for ensuring and documenting information to verify that the sale or installation of every “Race Only” part is for competition racing vehicle use only. Examples of such documentation include: • Require that the buyer of the part(s) sign an acknowledgement that the part is for “Race Use Only.” The acknowledgement would contain enough information (i.e., invoice number, purchase date, purchaser name, part number, etc.) to be able to track the part to its ultimate installation. • Evidence that the vehicle is not registered in any State for highway use. • The detailed owner or operator information and vehicle VIN are recorded. • The vehicle is being used in only closed course competition events like King of the Baggers®, BRL Bagger Racing League®, SUPER HOOLIGAN®, AMA FLAT TRACK®, or one of the hundreds of similar competition racing use only events throughout the US (road race, flat track, drag racing and land speed). If you have questions regarding the information that you should collect as evidence that the part purchased from LeMans and sold or installed by you/your company will be used only on a “Race Only” vehicle as intended, please refer to your legal counsel or racing trade association. This notice is a material condition of LeMans’ willingness to sell the product to you. By accepting the terms: 1. You are solely responsible to verify and document that use of “Race Only” parts will be limited to competition racing use consistent with the terms of this notice on each individual sales transaction; 2. You will provide LeMans with copies of the documentation that shows evidence of the use of “Race Only” parts purchased from LeMans upon request; and 3. You consent to the disclosure of your identity to any governmental entity responsible for regulating emissions and/or enforcing emissions laws, if requested. NOISE REGULATIONS A number of jurisdictions/states have exhaust noise laws. Exhaust products advertised might not be legal for sale or use on highway vehicles in such jurisdictions/states. Check applicable laws and regulations.

8 Windshields........................ 10-47 Fairings........................... 48-68 FairingTrim..................... 69-79,83 Brackets And Mounts.. . . . . . . . . . . . . . . . . 80-82 FairingPouches..................... 84-85 WINDSHIELDS & FAIRINGS

dragspecialties.com All part numbers in BLUE are new for 2025. SECTION 1 WINDSHIELDS & FAIRINGS AUDIO, COMMUNICATION & MOUNTS SADDLEBAGS & LUGGAGE SEATS & SISSY BARS FUEL/AIR SYSTEMS EXHAUST TRANSMISSION & DRIVELINE ENGINE GASKETS & SEALS LIGHTING ELECTRICAL HANDLEBARS, CONTROLS & MIRRORS CABLES TANKS & OIL FILTERS BRAKES DASHES & GAUGES FENDERS & LICENSE PLATE FRAMES HARDWARE, COVERS & GENERAL FRAMES & SUSPENSION FOOTRESTS & FLOORBOARDS WHEELS & AXLES 10 See OLDBOOK For Early Model Applications PART # DESCRIPTION FOR 24 FLHX, 23-24 FLHXSE 2310-0857 8” black 2310-0858 8” clear 2310-0859 8” dark smoke 2310-0860 8” tint FOR 24 FLHTK, 14-23 FLHT/FLHX/FLHXS/FLHXST, 14-24 FLHTCUTG (EXCEPT 23-24 FLHXSE) 2310-0479 11.5” clear 2310-0478 11.5” tint 2310-0634 11.5” dark smoke 2310-0682 10.5” clear 2310-0683 10.5” tint 2310-0684 10.5” dark smoke 2310-0476 8.5” tint 2310-0477 8.5” dark smoke 2310-0824 6.5” clear 2310-0473 6.5” tint 2310-0474 6.5” dark smoke 2310-0475 6.5” black FLARE™ WINDSHIELDS •Wind tunnel designed and tested, the “hips” provide added downforce for stability while the “flip” at the tip directs air up and over the rider to help eliminate swirling and buffeting •Made from unmatched durability Lexan® polycarbonate with FMR hard coating on both sides of the windshield •All are predrilled for easy mounting using stock windshield hardware •Made in the U.S.A. NOTE: The black version may not be suitable for shorter riders as it’s an opaque material. The Klock Werks Flare™ Windshields are protected under United States Patents: D632235S, D586274S, D586275S, D633017S, D626046S, D633018S And also under International Patents: 324093, 324094, 325192. Wind tunnel designed and tested 11.5” 10.5” 8.5” 6.5” 5” 4” 2310-0474 6.5” Dark smoke 2310-0477 8.5” Dark smoke 2310-0858 8” Dark smoke

dragspecialties.com All part numbers in BLUE are new for 2025. SECTION 1 WINDSHIELDS & FAIRINGS AUDIO, COMMUNICATION & MOUNTS SADDLEBAGS & LUGGAGE SEATS & SISSY BARS FUEL/AIR SYSTEMS EXHAUST TRANSMISSION & DRIVELINE ENGINE GASKETS & SEALS LIGHTING ELECTRICAL HANDLEBARS, CONTROLS & MIRRORS CABLES TANKS & OIL FILTERS BRAKES DASHES & GAUGES FENDERS & LICENSE PLATE FRAMES HARDWARE, COVERS & GENERAL FRAMES & SUSPENSION FOOTRESTS & FLOORBOARDS WHEELS & AXLES 12 See OLDBOOK For Early Model Applications PART # DESCRIPTION FOR 22-24 FXLRST 2310-0770 10” dark smoke 2310-0831 8” dark smoke 2310-0761 6” dark smoke FLARE™ WINDSHIELDS •Wind tunnel designed and tested, the “hips” provide added downforce for stability while the “flip” at the tip directs air up and over the rider to help eliminate swirling and buffeting •Made from unmatched durability Lexan® polycarbonate with FMR hard coating on both sides of the windshield •All are predrilled for easy mounting using stock windshield hardware •Made in the U.S.A. The Klock Werks Flare™ Windshields are protected under United States Patents: D632235S, D586274S, D586275S, D633017S, D626046S, D633018S and also under International Patents: 324093, 324094, 325192. PART # DESCRIPTION 2310-0774 For 21-24 RA1250/RA1250S FLARE™ WINDSHIELD •Wind tunnel designed and tested, the “hips” provide added downforce for stability while the “flip” at the tip directs air up and over the rider to help eliminate swirling and buffeting •Made from unmatched durability Lexan® polycarbonate with FMR hard coating on both sides of the windshield •Available in 15.5” tint •Predrilled for easy mounting using stock windshield hardware •Made in the U.S.A. The Klock Werks Flare™ Windshields are protected under United States Patents: D632235S, D586274S, D586275S, D633017S, D626046S, D633018S And also under International Patents: 324093, 324094, 325192. PART # DESCRIPTION 2310-0690 For 18-21 FLSB SPORT GLIDE® WINDSHIELD •This functional, dark smoke windshield is designed to keep a low sport profile •New design kicks up the air to create a less-turbulent wind pocket •Measures approximately 8” from the lip of the fairing to the top of the windshield •Made in the U.S.A. 2310-0831 2310-0770 2310-0761 6” 10”

dragspecialties.com SECTION 1 All part numbers in BLUE are new for 2025. WINDSHIELDS & FAIRINGS AUDIO, COMMUNICATION & MOUNTS SADDLEBAGS & LUGGAGE SEATS & SISSY BARS FUEL/AIR SYSTEMS EXHAUST TRANSMISSION & DRIVELINE ENGINE GASKETS & SEALS LIGHTING ELECTRICAL HANDLEBARS, CONTROLS & MIRRORS CABLES TANKS & OIL FILTERS BRAKES DASHES & GAUGES FENDERS & LICENSE PLATE FRAMES HARDWARE, COVERS & GENERAL FRAMES & SUSPENSION FOOTRESTS & FLOORBOARDS WHEELS & AXLES 13 See OLDBOOK For Early Model Applications SPORT FLARE™ PART # DESCRIPTION FOR 24 FLTRX/FLTRXSTSE, 23-24 FLTRXSE 2310-0853 10” black 2310-0854 10” clear 2310-0855 10” dark smoke 2310-0856 10” tint FOR 24 FLTRK, 23-24 FLTRT, 15-23 FLTRX/FLTRXS/FLTRXST/ FLTRK/FLTRU (EXCEPT 24 FLTRX/FLTRXSTSE, 23-24 FLTRXSE) 2310-0569 14” tint 2310-0570 14” dark smoke 2310-0750 11” tint 2310-0751 11” dark smoke 2310-0822 9” clear 2310-0581 9” dark smoke PART # DESCRIPTION FOR 24 FLTRK, 23-24 FLTRT, 15-23 FLTRX/FLTRXS/FLTRXST/ FLTRK/FLTRU (EXCEPT 24 FLTRX/FLTRXSTSE, 23-24 FLTRXSE) (CONT) 2310-0582 9” black 2310-0821 6” clear 2310-0670 6” dark smoke 2310-0671 6” black FOR 99-13 FLTR/FLTRX/FLTRU 2310-0194 12” tint 2310-0358 12” dark smoke 2310-0207 8” tint 2310-0214 8” dark smoke 2310-0196 8” black FLARE™ WINDSHIELDS •Two styles available: Pro Touring and Sport •The Pro Touring Flare™ is a wider, more full-coverage option for riders and passengers looking for greater wind protection during long-haul touring, yet is stylish enough for use around town •The Sport Flare™ is more streamlined and offers radical curves and a sportier stance; it complements the lines of the new fairing with a more aggressive profile and adds stability and handling with improved air management •The patented design features “hips” at the sides that re-route air away from the rider while adding downforce to the front end to improve stability and handling compared to the stock windshield design (the stock design creates lift) •The “flip” at the top of the Flare™ kicks air up and over the rider creating cleaner, less turbulent air for the rider and passenger •Wind tunnel tested and designed for maximum performance and air management •Made of Lexan® Polycarbonate with FMR hard coating on both sides of the shield for unmatched durability •All are predrilled for easy mounting using stock windshield hardware •Made in the U.S.A. NOTE: The black version may not be suitable for shorter riders as it’s an opaque material. The Klock Werks Flare™ Windshields are protected under United States Patents: D632235S, D586274S, D586275S, D633017S, D626046S, D633018S. And also under International Patents: 324093, 324094, 325192. 2310-0821 6” Clear 2310-0570 14” Dark smoke 2310-0581 9” Dark smoke FLARE™ WINDSHIELDS continued on next page. 2310-0358 12” Dark smoke 2310-0196 8” Dark smoke

dragspecialties.com SECTION 1 All part numbers in BLUE are new for 2025. WINDSHIELDS & FAIRINGS AUDIO, COMMUNICATION & MOUNTS SADDLEBAGS & LUGGAGE SEATS & SISSY BARS FUEL/AIR SYSTEMS EXHAUST TRANSMISSION & DRIVELINE ENGINE GASKETS & SEALS LIGHTING ELECTRICAL HANDLEBARS, CONTROLS & MIRRORS CABLES TANKS & OIL FILTERS BRAKES DASHES & GAUGES FENDERS & LICENSE PLATE FRAMES HARDWARE, COVERS & GENERAL FRAMES & SUSPENSION FOOTRESTS & FLOORBOARDS WHEELS & AXLES 15 See OLDBOOK For Early Model Applications PART # DESCRIPTION FOR 24 FLTRX/FLTRXSTSE, 23-24 FLTRXSE 2310-0861 10” pink 2310-0862 10” orange 2310-0863 10” yellow 2310-0864 10” green 2310-0865 10” blue FOR 24 FLHX, 23-24 FLHXSE 2310-0873 8” pink 2310-0874 8” orange 2310-0875 8” yellow 2310-0876 8” green 2310-0877 8” blue FOR 24 FLTRK, 23-24 FLTRT, 15-23 FLTRX/FLTRK/FLTRU (EXCEPT 24 FLTRX/FLTRXSTSE, 23-24 FLTRXSE) 2310-0732 9” blue 2310-0731 9” green 2310-0729 9” yellow 2310-0728 9” orange 2310-0730 9” pink PART # DESCRIPTION FOR 24 FLTRK, 23-24 FLTRT, 15-23 FLTRX/FLTRK/FLTRU (EXCEPT 24 FLTRX/FLTRXSTSE, 23-24 FLTRXSE) (CONT) 2310-0727 6” blue 2310-0726 6” green 2310-0724 6” yellow 2310-0723 6” orange 2310-0725 6” pink FOR 24 FLHTK, 14-23 FLHT/FLHX, 14-24 FLHTCUTG (EXCEPT 24 FLHX, 23-24 FLHXSE) 2310-0742 6.5” blue 2310-0741 6.5” green 2310-0739 6.5” yellow 2310-0738 6.5” orange 2310-0740 6.5” pink 2310-0747 4” blue 2310-0746 4” green 2310-0744 4” yellow 2310-0743 4” orange 2310-0745 4” pink PART # DESCRIPTION FOR 99-13 FLHT/FLHTC/FLHX AND 09-13 H-D FL TRIKE 2310-0737 6.5” blue 2310-0736 6.5” green 2310-0734 6.5” yellow 2310-0733 6.5” orange 2310-0735 6.5” pink 2310-0760 3.5” blue 2310-0759 3.5” green 2310-0757 3.5” yellow 2310-0756 3.5” orange 2310-0758 3.5” pink FOR 99-13 FLTR/FLTRX 2310-0722 8” blue 2310-0721 8” green 2310-0719 8” yellow 2310-0718 8” orange 2310-0720 8” pink ICE KOLOR FLARE™ WINDSHIELDS •Wind tunnel designed and tested, the “hips” provide added downforce while the flip at the tip directs air over the rider to help eliminate the swirl of air found in front of the rider on standard windshields •Windshields are made from acrylic and have a vibrant fluorescent edge to give your motorcycle a little extra pop •All are predrilled for easy mounting using stock windshield hardware •Pink Ice windshields were previously cataloged as Red Ice •Made in the U.S.A. The Klock Werks Flare™ Windshields are protected under United States Patents: D632235S, D586274S, D586275S, D633017S, D626046S, D633018S and also under International Patents: 324093, 324094, 325192.

dragspecialties.com All part numbers in BLUE are new for 2025. SECTION 1 WINDSHIELDS & FAIRINGS AUDIO, COMMUNICATION & MOUNTS SADDLEBAGS & LUGGAGE SEATS & SISSY BARS FUEL/AIR SYSTEMS EXHAUST TRANSMISSION & DRIVELINE ENGINE GASKETS & SEALS LIGHTING ELECTRICAL HANDLEBARS, CONTROLS & MIRRORS CABLES TANKS & OIL FILTERS BRAKES DASHES & GAUGES FENDERS & LICENSE PLATE FRAMES HARDWARE, COVERS & GENERAL FRAMES & SUSPENSION FOOTRESTS & FLOORBOARDS WHEELS & AXLES 16 See OLDBOOK For Early Model Applications PART # DESCRIPTION FOR 24 FLHX, 23-24 FLHXSE 2310-0878 8” red 2310-0879 8” orange 2310-0880 8” yellow 2310-0881 8” green 2310-0882 8” blue 2310-0883 8” purple 2310-0884 8” bronze PART # DESCRIPTION FOR 24 FLHTK, 14-23 FLHT/FLHX, 14-24 FLHTCUTG (EXCEPT 24 FLHX, 23-24 FLHXSE) 2310-0795 4” orange 2310-0796 4” yellow 2310-0797 4” red 2310-0798 4” green 2310-0799 4” blue 2310-0800 4” purple 2310-0801 4” bronze PART # DESCRIPTION FOR 24 FLHTK, 14-23 FLHT/FLHX, 14-24 FLHTCUTG (EXCEPT 24 FLHX, 23-24 FLHXSE) (CONT) 2310-0802 6.5” orange 2310-0803 6.5” yellow 2310-0804 6.5” red 2310-0805 6.5” green 2310-0806 6.5” blue 2310-0807 6.5” purple 2310-0808 6.5” bronze KOLOR FLARE™ WINDSHIELDS •Wind tunnel designed and tested, the “hips” provide added downforce while the flip at the tip directs air over the rider to help eliminate the swirl of air found in front of the rider on standard windshields •Windshields are made from acrylic •All are predrilled for easy mounting using stock windshield hardware •Made in the U.S.A. 2310-0802 2310-0803 2310-0804 2310-0805 2310-0806 2310-0807 2310-0808 2310-0879 2310-0881 2310-0883 The Klock Werks Flare™ Windshields are protected under United States Patents: D632235S, D586274S, D586275S, D633017S, D626046S, D633018S and also under International Patents: 324093, 324094, 325192.

dragspecialties.com All part numbers in BLUE are new for 2025. SECTION 1 WINDSHIELDS & FAIRINGS AUDIO, COMMUNICATION & MOUNTS SADDLEBAGS & LUGGAGE SEATS & SISSY BARS FUEL/AIR SYSTEMS EXHAUST TRANSMISSION & DRIVELINE ENGINE GASKETS & SEALS LIGHTING ELECTRICAL HANDLEBARS, CONTROLS & MIRRORS CABLES TANKS & OIL FILTERS BRAKES DASHES & GAUGES FENDERS & LICENSE PLATE FRAMES HARDWARE, COVERS & GENERAL FRAMES & SUSPENSION FOOTRESTS & FLOORBOARDS WHEELS & AXLES 20 See OLDBOOK For Early Model Applications PART # DESCRIPTION FOR 22-24 FXLRST 2310-0832 6” red 2310-0833 6” orange 2310-0834 6” yellow 2310-0835 6” green 2310-0836 6” blue PART # DESCRIPTION FOR 22-24 FXLRST (CONT) 2310-0837 6” purple 2310-0838 6” bronze 2310-0839 8” red 2310-0840 8” orange 2310-0841 8” yellow PART # DESCRIPTION FOR 22-24 FXLRST (CONT) 2310-0842 8” green 2310-0843 8” blue 2310-0844 8” purple 2310-0845 8” bronze KOLOR FLARE™ WINDSHIELDS •The Kolor Flare™ is streamlined and offers radical curves and a sportier stance; it complements the lines of the new fairing with a more aggressive profile and adds stability and handling with improved air management •The patented design features “hips” at the sides that re-route air away from the rider while adding downforce to the front end to improve stability and handling compared to the stock windshield design (the stock design creates lift) •The “flip” at the top of the Flare™ kicks air up and over the rider creating cleaner, less turbulent air for the rider and passenger •Wind tunnel tested and designed for maximum performance and air management •Windshields are made from acrylic •All are predrilled for easy mounting using stock windshield hardware •Made in the U.S.A. The Klock Werks Flare™ Windshields are protected under United States Patents: D632235S, D586274S, D586275S, D633017S, D626046S, D633018S and also under International Patents: 324093, 324094, 325192. 2310-0844 2310-0842 2310-0840 2310-0838 2310-0832 2310-0834 2310-0836

dragspecialties.com SECTION 1 All part numbers in BLUE are new for 2025. WINDSHIELDS & FAIRINGS AUDIO, COMMUNICATION & MOUNTS SADDLEBAGS & LUGGAGE SEATS & SISSY BARS FUEL/AIR SYSTEMS EXHAUST TRANSMISSION & DRIVELINE ENGINE GASKETS & SEALS LIGHTING ELECTRICAL HANDLEBARS, CONTROLS & MIRRORS CABLES TANKS & OIL FILTERS BRAKES DASHES & GAUGES FENDERS & LICENSE PLATE FRAMES HARDWARE, COVERS & GENERAL FRAMES & SUSPENSION FOOTRESTS & FLOORBOARDS WHEELS & AXLES 21 See OLDBOOK For Early Model Applications FOR 99-24 FLHR AND 12-16 FLD WITH OEM ACCESSORY DETACHABLE KING-SIZE WINDSHIELD PART # DESCRIPTION 19 3/8” TALL X 26 5/8” WIDE 2310-0342 Clear 2310-0341 Tint 2310-0709 Dark smoke PART # DESCRIPTION 16 1/2” TALL x 26 1/2” WIDE 2310-0387 Clear 2310-0388 Tint 2310-0708 Dark smoke FOR 18-24 FLHC/FLHCS/FLDE PART # DESCRIPTION 20 1/4” TALL x 26 1/4” WIDE 2310-0686 Clear 2310-0687 Tint 2310-0712 Dark smoke PART # DESCRIPTION 17” TALL x 26 3/8” WIDE 2310-0688 Clear 2310-0689 Tint 2310-0713 Dark smoke FLARE™ BILLBOARD WINDSHIELDS •Modeled after the original Flare™ windshield for Baggers; now almost every rider can get all of the same performance and style with bolt-on ease •Patented Klock Werks “hips” on each side create downforce for added stability and the “flip” at the top kicks air up and over the rider for a smoother, less turbulent ride •Wind tunnel tested and designed to create the same downforce as the original Flare™ windshield •Computer simulations and real-world testing have resulted in multiple windshield heights to ensure a windshield size that will work for almost any rider •Windshield heights listed are measured from the top of the headlight opening to the top of the windshield •Pre-drilled for easy mounting using stock windshield mounting kits •For the following applications “Detachable” refers to the old-style H-D grommet/hinge style mechanism •Made in the U.S.A. NOTE: All measurements given are approximate. The Klock Werks Flare™ Windshields are protected under United States Patents: D632235S, D586274S, D586275S, D633017S, D626046S, D633018S and also under International Patents: 324093, 324094, 325192. FLARE™ BILLBOARD WINDSHIELDS continued on next page. 2310-0712 2310-0341 2310-0342 2310-0687

dragspecialties.com SECTION 1 All part numbers in BLUE are new for 2025. WINDSHIELDS & FAIRINGS AUDIO, COMMUNICATION & MOUNTS SADDLEBAGS & LUGGAGE SEATS & SISSY BARS FUEL/AIR SYSTEMS EXHAUST TRANSMISSION & DRIVELINE ENGINE GASKETS & SEALS LIGHTING ELECTRICAL HANDLEBARS, CONTROLS & MIRRORS CABLES TANKS & OIL FILTERS BRAKES DASHES & GAUGES FENDERS & LICENSE PLATE FRAMES HARDWARE, COVERS & GENERAL FRAMES & SUSPENSION FOOTRESTS & FLOORBOARDS WHEELS & AXLES 23 See OLDBOOK For Early Model Applications PART # DESCRIPTION 15” TALL MEM4110 Clear MEM4119 Solar 2313-0274 Black smoke 2313-0276 Dark black smoke 17” TALL MEM4210 Clear MEM4219 Solar 2313-0278 Black smoke PART # DESCRIPTION 15” TALL 2311-0112 “Night Shades” clear 2311-0113 “Night Shades” dark black smoke 2311-0114 “Night Shades” black smoke 17” TALL 2311-0115 “Night Shades” clear 2311-0116 “Night Shades” black smoke FOR 5 3/4”-7” HEADLIGHT CUTOUTS PART # DESCRIPTION 15” TALL 2313-0275 Black smoke 2313-0277 Dark black smoke 2313-0317 “Night Shades” clear 2313-0318 “Night Shades” dark black smoke 2313-0319 “Night Shades” black smoke MEM4120 Clear MEM4129 Solar 17” TALL 2313-0279 Black smoke MEM4229 Dark black smoke 2313-0320 “Night Shades” clear 2313-0321 “Night Shades” black smoke MEM4220 Clear FOR 7” HEADLIGHT CUTOUTS FOR 9” HEADLIGHT CUTOUTS MEMPHIS SLIM •Slimmed-down version of Memphis Fats is 18” wide •Available in clear, solar (a light tint with 72% visible light transmission), black smoke and dark black smoke •Available in 15” and 17” heights •Made of Lucite® for excellent optics and durability •Windshield straps are available in polished stainless steel with CNC-machined billet aluminum fittings and stainless steel socket-head screws or the “Night Shades” version with black E-coated stainless steel straps, fittings and hardware for a black-on-black sinister look •No-Tool detachable Trigger-Lock mounting hardware must be ordered separately; available in polished or “Night Shades” black, see pages 31-32 •Optional Lowers available for additional windshield coverage; see page 28 •Made in the U.S.A. 2311-0114 “Night Shades” Black Smoke 2313-0278 Black smoke 2313-0279 Black smoke MEM4110 Clear 2313-0276 Dark black smoke MEM4219 Solar

dragspecialties.com All part numbers in BLUE are new for 2025. SECTION 1 WINDSHIELDS & FAIRINGS AUDIO, COMMUNICATION & MOUNTS SADDLEBAGS & LUGGAGE SEATS & SISSY BARS FUEL/AIR SYSTEMS EXHAUST TRANSMISSION & DRIVELINE ENGINE GASKETS & SEALS LIGHTING ELECTRICAL HANDLEBARS, CONTROLS & MIRRORS CABLES TANKS & OIL FILTERS BRAKES DASHES & GAUGES FENDERS & LICENSE PLATE FRAMES HARDWARE, COVERS & GENERAL FRAMES & SUSPENSION FOOTRESTS & FLOORBOARDS WHEELS & AXLES 24 See OLDBOOK For Early Model Applications MEMPHIS FATS •Features traditional American styling available in clear, solar (a light tint with 72% visible light transmission), “Night Shades” black smoke (a black tint with 40% visible light transmission) and “Night Shades” dark black smoke (a black tint with 25% visible light transmission) •Made from Lucite® for excellent optics and durability •22” W with five standard heights to choose from •Windshield straps are available in polished stainless steel with CNC-machined billet aluminum fittings and stainless steel socket-head screws or the “Night Shades” black version which is a gradient black windshield with black E-coated stainless steel straps, fittings and hardware for a black-on-black sinister look •No-Tool detachable Trigger-Lock mounting hardware must be ordered separately; available in polished or “Night Shades” black, see pages 31-32 •Optional Lowers available for additional coverage; see page 28 •Made in the U.S.A. PART # DESCRIPTION 13” TALL MEM3110 Clear MEM3119 Solar 2313-0260 Black smoke 2313-0262 Dark black smoke 15” TALL 2313-0064 Clear 2313-0072 Solar 2313-0264 Black smoke 2313-0266 Dark black smoke 17” TALL MEM3210 Clear PART # DESCRIPTION 17” TALL (CONT) MEM3219 Solar 2313-0268 Black smoke 19” TALL MEM3310 Clear MEM3319 Solar 2313-0270 Black smoke 21” TALL MEM3410 Clear MEM3419 Solar 2313-0272 Black smoke PART # DESCRIPTION 13” TALL 2311-0100 “Night Shades” clear 2311-0101 “Night Shades” dark black smoke 2311-0102 “Night Shades” black smoke 15” TALL 2311-0103 “Night Shades” clear 2311-0104 “Night Shades” dark black smoke 2311-0105 “Night Shades” black smoke 17” TALL 2311-0106 “Night Shades” clear 2311-0107 “Night Shades” black smoke PART # DESCRIPTION 19” TALL 2311-0108 “Night Shades” clear 2311-0109 “Night Shades” black smoke 21” TALL 2311-0110 “Night Shades” clear 2311-0111 “Night Shades” black smoke FOR 5 3/4”-7” HEADLIGHT CUTOUTS FOR 7” HEADLIGHT CUTOUTS “Night Shades” clear Dark black smoke Black smoke Solar

dragspecialties.com SECTION 1 All part numbers in BLUE are new for 2025. WINDSHIELDS & FAIRINGS AUDIO, COMMUNICATION & MOUNTS SADDLEBAGS & LUGGAGE SEATS & SISSY BARS FUEL/AIR SYSTEMS EXHAUST TRANSMISSION & DRIVELINE ENGINE GASKETS & SEALS LIGHTING ELECTRICAL HANDLEBARS, CONTROLS & MIRRORS CABLES TANKS & OIL FILTERS BRAKES DASHES & GAUGES FENDERS & LICENSE PLATE FRAMES HARDWARE, COVERS & GENERAL FRAMES & SUSPENSION FOOTRESTS & FLOORBOARDS WHEELS & AXLES 25 See OLDBOOK For Early Model Applications PART # DESCRIPTION 13” TALL 2313-0003 Clear 2313-0261 Black smoke 2313-0263 Dark black smoke 2313-0305 “Night Shades” clear 2313-0306 “Night Shades” dark black smoke 2313-0307 “Night Shades” black smoke 15” TALL 2313-0073 Clear 2313-0081 Solar 2313-0265 Black smoke 2313-0267 Dark black smoke 2313-0308 “Night Shades” clear 2313-0309 “Night Shades” dark black smoke 2313-0310 “Night Shades” black smoke 17” TALL MEM3620 Clear MEM3629 Solar PART # DESCRIPTION 17” TALL (CONT) 2313-0269 Black smoke 2313-0311 “Night Shades” clear 2313-0312 “Night Shades” black smoke 19” TALL MEM3710 Clear MEM3719 Solar 2313-0271 Black smoke 2313-0313 “Night Shades” clear 2313-0314 “Night Shades” black smoke 21” TALL MEM3810 Clear MEM3819 Solar 2313-0273 Black smoke 2313-0315 “Night Shades” clear 2313-0316 “Night Shades” black smoke MEMPHIS FATS (CONT) FOR 9” HEADLIGHT CUTOUTS PART # DESCRIPTION FOR 08-17 FXDF 2313-0122 13” tall 2313-0128 15” tall PART # DESCRIPTION FOR 08-17 FXDF (CONT) 2313-0134 17” tall 2313-0140 19” tall PART # DESCRIPTION FOR 08-17 FXDF (CONT) 2313-0146 21” tall MEMPHIS FATS FOR FXDF •Feature traditional American styling with a unique cutout for dual headlight •Five standard heights to choose from: 13”, 15”, 17”, 19” and 21” •Available in clear •Windshield straps are polished stainless steel with billet aluminum fittings and stainless steel socket-head screws •No-Tool detachable Trigger-Lock mounting hardware must be ordered separately; available in polished or “Night Shades” black, pages 31-32 •Made from Lucite® for excellent optics and durability •Made in the U.S.A. 2313-0146 PART # DESCRIPTION 2313-0049 15” tall PART # DESCRIPTION 2313-0054 17” tall PART # DESCRIPTION 2313-0059 19” tall MEMPHIS FATS WITH BIG HEADLIGHT CUTOUT •Feature a 9.5” cutout with a custom shape that is designed for a perfect fit on the large nacelle headlights made by Arlen Ness, Rick Doss and others •Available in clear •Made from Lucite® for excellent optics and durability •22” W with three standard heights •Windshield straps are polished stainless steel with CNC-machined billet aluminum fittings and stainless steel socket-head screws •No-Tool detachable Trigger-Lock mounting hardware must be ordered separately; available in polished or “Night Shades” black, see pages 31-32 •Optional Lowers available for additional windshield coverage, see page 28 •Made in the U.S.A. 2313-0054

dragspecialties.com All part numbers in BLUE are new for 2025. SECTION 1 WINDSHIELDS & FAIRINGS AUDIO, COMMUNICATION & MOUNTS SADDLEBAGS & LUGGAGE SEATS & SISSY BARS FUEL/AIR SYSTEMS EXHAUST TRANSMISSION & DRIVELINE ENGINE GASKETS & SEALS LIGHTING ELECTRICAL HANDLEBARS, CONTROLS & MIRRORS CABLES TANKS & OIL FILTERS BRAKES DASHES & GAUGES FENDERS & LICENSE PLATE FRAMES HARDWARE, COVERS & GENERAL FRAMES & SUSPENSION FOOTRESTS & FLOORBOARDS WHEELS & AXLES 28 See OLDBOOK For Early Model Applications PART # DESCRIPTION 2350-0200 Side Wings SIDE WINGS •Expand comfort pocket, channeling air outward while “cleaning” the flow •Adjust to suit rider preference •Can be installed/removed with windshield intact – Santoprene pads grip the windshield but do not mar the surface •”Ghost” shade – a neutral tint with 85% light transmission barely noticeable, with just enough tint to make the edges disappear •Fit Road King, Fat Boy, Heritage and Memphis Fats windshield using injection-molded glass-filled nylon clamps in place of the billet aluminum clamps (can be mounted along with Hot Wing) •Sold in pairs PART # DESCRIPTION 2350-0199 Hot Wing HOT WING •Boosts airstream upward – Venturi action speeds up the airstream while smoothing the flow – without buffeting •Allows the use of a shorter shield; now you can easily look over your shield •Made with “Ghost” shade – a neutral tint with 85% light transmission; barely noticeable, with just enough tint to make the edges disappear •Uses lightweight, economical injection-molded glass-filled nylon clamps; fits Memphis Fats windshields or similar windshields that measure 3 mm or 4.5 mm thick (includes inserts for both sizes) •Made in the U.S.A. PART # DESCRIPTION MEP5810 Clear PART # DESCRIPTION MEP5811 Black PART # DESCRIPTION MEP5819 Solar CUSTOM LOWERS •Provide additional protection by extending your coverage downward •Shield rider from rain, wind and noise coming up from the road •Made of the same high-quality materials as Memphis Shades windshields with matching tints •Available in clear, black and solar (a light tint with 72% visible light transmission) •Must purchase Lowers mounting kits; see pages 31-32 •May require turn signal relocation •Measure 8” H x 5 – 5 1/2” W •Sold in pairs •Made in the U.S.A. Black Solar Clear
